Guide: Creating your own NAS with Open Media Vault and Proxmox

Using OpenMediaVault (OMV) as a NAS solution on a Proxmox setup is a powerful combination, especially when paired with an external storage enclosure like the TerraMaster D4-300 USB-C. This setup provides a flexible, scalable, and centralized storage solution for your home lab or small business, allowing you to manage drives and media easily within a virtualized environment.

In this guide, I’ll walk you through installing OMV inside Proxmox and configuring your TerraMaster D4-300 USB-C enclosure for storage.

Prerequisites:

• Proxmox Server: A running Proxmox server with at least one VM allocation available.
• OpenMediaVault ISO: Download the latest OMV ISO from the OpenMediaVault website.
• External USB-C TerraMaster: A TerraMaster D4-300 or compatible USB-C external storage enclosure connected to your Proxmox server.
• Available Drives: Install drives in the TerraMaster enclosure for storage.

Setting Up an OMV Virtual Machine in Proxmox

Upload the OMV ISO to Proxmox:

• In the Proxmox web UI, go to Datacenter > [Your Node] > ISO Images.
• Upload the OMV ISO file to Proxmox.

Create a New Virtual Machine:

• In Proxmox, go to Create VM and set up the VM with the following specifications:
• Name: Choose a descriptive name, like “OMV-NAS.”
• OS: Select “Do not use any media” and continue.
• CD/DVD Drive: Choose the OMV ISO from the storage you uploaded it to.
• CPU: Assign at least 2 cores for better performance.
• Memory: Set 2-4GB of RAM, depending on the expected load.
• Disk: Allocate 16GB or more for the main OMV installation.
• Complete the setup and Start the VM.

Install OpenMediaVault:

• Once the VM boots, follow the installation wizard to install OMV on the virtual disk.
• Set up the default admin user and password as prompted.
• After installation, OMV will reboot, and you can log in to the web interface via the IP address assigned to your VM.

Configuring OMV to Use Your TerraMaster USB-C Enclosure

Connect the TerraMaster to Proxmox:

• Ensure your TerraMaster is connected to the Proxmox server via USB-C and that all intended drives are inserted.
• In the Proxmox web UI, navigate to Datacenter > [Your Node] > Hardware to confirm that Proxmox detects the TerraMaster drives.

Pass Through the TerraMaster USB Device to the OMV VM:

• To make OMV recognize the TerraMaster drives, go to OMV-NAS VM > Hardware > Add > USB Device.
• Select the TerraMaster USB-C device from the dropdown list and confirm.
• Restart the OMV VM to apply the changes.

Verify Drive Detection in OMV:

• Log in to the OMV web interface and go to Storage > Disks.
• You should see the TerraMaster drives listed. If they’re not appearing, confirm the USB pass-through setup and reboot the VM.

Formatting and Mounting the Drives in OMV

Format the Drives:

• In OMV, navigate to Storage > Disks and select each drive from the TerraMaster enclosure.
• Choose the Wipe option to prepare the drives. Be cautious, as this will erase any data on them.

Create File Systems:

• After wiping, go to Storage > File Systems > Create.
• Choose each TerraMaster drive, select the filesystem type (e.g., EXT4 or BTRFS), and confirm.

Mount the Drives:

• Once the filesystems are created, select each drive and click Mount.
• OMV will add the drives to the mounted list, making them available for storage.

Setting Up Shared Folders and SMB/CIFS for Network Access

• Create Shared Folders:
• Go to Storage > Shared Folders > Add.
• Assign each TerraMaster drive to a shared folder, setting a name and path.

Enable SMB/CIFS for Network Access:

• Navigate to Services > SMB/CIFS and enable it.
• Add the shared folders under Shares and configure access permissions as needed.

Connect to Shared Folders:

• On any device within your network, access the shared folders by entering the OMV IP in the file explorer (e.g., \\[OMV-IP-Address]).

Additional Configuration and Tips

• Setup User Accounts: In OMV, you can create specific users and assign them permissions to different shared folders for enhanced security.
• Install Plugins: OMV offers various plugins for media management, backup solutions, and monitoring. Check the OMV-Extras plugin for additional options.
• Monitor Performance: Use OMV’s system information dashboard to keep an eye on disk usage, CPU load, and memory.

Conclusion

This setup provides a cost-effective, flexible NAS solution by combining Proxmox’s virtualization with OMV’s storage management capabilities. The TerraMaster D4-300 USB-C enclosure adds expandability and drive flexibility, making it a perfect match for Proxmox users needing centralized storage.

With OMV running in a VM on Proxmox, you get the best of both worlds containerized storage with a modular setup, and the ability to add or upgrade drives as needed. Try this setup in your own lab to enhance your storage capabilities without a full NAS hardware investment!
